MEN POWER SUPPLY 1/2-PHASE, SMOOTHED

IN: 115/230+/-10VAC OUT: :24V/5ADC

Art. nr.:	85362
Vægt:	3 kg
Country of origin:	CZ

Ikke på lager - Kontakt os for leveringsdato

Find similar Product

Stil et spørgsmål

Anbefale dette produkt

Produktsammenligning

Beskrivelse

Current: 5 A
Output rating: 120 W
This power supply units meet the (EN 61000-3-2) standard for harmonic current.
For any mounting position at vertical wall.

Tekniske specifikationer

General data

Standards	EN 61558-2-6, EN 62041 category I, EN 55011 B, EN 61000-3-2
Mounting method	Key-hole mounting
Temperature range	-20...+60 °C, no condensation
Fixing centers a×b×c	75×84×5.8 mm
Dimensions H×W×D	95×96×136 mm

Output

Output voltage	24 V DC (SELV)
Output current (Ta 60/40 °C)	max. 5 A (115 V AC); 6 A (230 V AC)
Output suppression	LED, VDR and smoothing capacitor
Output fuse	10 A (automotive fuse FKS)
Ripple	max. 5% eff/rms

Input

Input voltage	115/230 V AC ±10 V AC
Input fuse (external)	3.15 AT (115 V AC); 1.6 AT (230 V AC)
Input current	2 A (115 V AC); 1 A (230 V AC)
Frequency	50...60 Hz

Product article number of manufacturer	85362

Commercial data

ECLASS-6.0	27049002
ECLASS-6.1	27049002
ECLASS-7.0	27049002
ECLASS-8.0	27049002
ECLASS-9.0	27040701
ECLASS-10.1	27040701
ECLASS-11.1	27040701
ECLASS-12.0	27040701
ETIM-5.0	EC002540
customs tariff number	85044095
EAN	4048879079976
Pakke-enhed	1
