MASI20 INSTALLATION TECHNOLOGY 55607
Produktet kan afvige fra billedet

MASI20 INSTALLATION TECHNOLOGY

Distributor AS-I and extern power, 3 potentials
Art. nr.: 55607
Vægt: 0.08 kg
Country of origin:  CZ
Tilgængelig
Stil et spørgsmål
 Anbefale dette produkt
 Produktsammenligning
Listepris pr. Stk:
Tilføj Easy-Import-Export

Beskrivelse

5 ports, universal
3 potentials
without plug terminals
Certificate
Certificate
Certificate

Electrical data | Supply
Operating voltage DC max. 36 V
Current operating per port max. 8 A
Total current max. 12 A
Device protection | Electrical
Insulation strength ASI/Power 200 V
Insulation strength Power/Power (EN 60664-1) 50 V
Degree of protection (EN IEC 60529) IP20
Mechanical data | Mounting data
Mounting method geschnappt
Suitable for mounting type (EN 60715), mounting rail
Height 43 mm
Width 25 mm
Depth 142 mm
Environmental characteristics | Climatic
Operating temperature min. -20 °C
Operating temperature max. 70 °C
Conformities, approvals, certificates
Product standard EN 60664-1

Connection types
Connection type 1 11
Connection type 2 12
Connection type 3 13
Connection type 4 21
Connection type 5 31
Connection type 6 123
Connection type 1
Connection Screw terminals SK
Family construction form terminal
Gender female
Color contact carrier green
No. of poles 2
Connection type 2
Connection Screw terminals SK
Family construction form terminal
Gender female
Color contact carrier green
No. of poles 2
Connection type 3
Connection Screw terminals SK
Family construction form terminal
Gender female
Color contact carrier green
No. of poles 2
Connection type 4
Connection Screw terminals SK
Family construction form terminal
Gender female
Color contact carrier green
No. of poles 2
Connection type 5
Connection Screw terminals SK
Family construction form terminal
Gender female
Color contact carrier green
No. of poles 2
Connection type 6
Connection Screw terminals SK
Family construction form terminal
Gender female
Color contact carrier green
No. of poles 6

ECLASS-6.0 27279219
ECLASS-6.1 27279219
ECLASS-7.0 27279219
ECLASS-8.0 27279219
ECLASS-9.0 27440108
ECLASS-10.1 27440111
ECLASS-11.1 27440111
ECLASS-12.0 27440111
ETIM-5.0 EC001596

customs tariff number 85366990
GTIN 4048879050487
Pakke-enhed 1


Oplysninger vedrørende artikel:
  • Hent Produkt-PDF
  • Hent Approval: UL Registered CA 55607_E201820-NRAQ8_urc_z_b.pdf
  • Hent Approval: UL Registered US 55607_E201820-NRAQ2_ur_z_b.pdf
  • Hent Construction files: DXF 55607_dxf_x_a.zip
  • Hent Construction files: P8 55607_p8_2_30.zip
  • Hent Construction files: P8 55575_p8_2_50.zip
  • Hent Construction files: STP 55607_stp_x_a.zip
  • Hent Document: Installation guide 55607_ina_5_12.pdf
  • Hent Information: Certificate of conformity Murrelektronik GmbH 05-02-23_(2) China RoHS 2 20EEP_DoC_z_a.pdf
  • Hent Information: Certificate of conformity Murrelektronik GmbH 20-10-21_(1) California Prop65 No Warning_DoC_z_b.pdf
  • Hent Information: Certificate of conformity Murrelektronik GmbH 13-11-20_(2) RoHS REACh exception 7cI_DoC_z_c.pdf
  • Hent Information: Certificate of conformity UKCA 55607_18-05.15_uk_z_a.pdf
  • Hent Information: EU declaration of conformity 55607_18-05.15_ce_z_a.pdf
  • Hent Information: MTTF Report 55607_SN29500(40°C)-BerechnungV1.4_mttf_p_a.pdf
