MVK I/O COMPACT MODULE, METAL
Produktet kan afvige fra billedet

MVK I/O COMPACT MODULE, METAL

CANopen, 8 multif.channels / 8 dig. In / Diag
Art. nr.: 55305
Alternative varer:    55306
Vægt: 0.822 kg
Tilgængelig
 Produktsammenligning
Listepris pr. Stk:

Du vil måske også kunne lide

General data
Mounting method 2-hole screw mounting
Temperature range 0...+55 °C (storage temperature -20...+70 °C)
Protection IP67
Dimensions H×W×D 42×63×225 mm
Module supply
Operating voltage 24 V DC (EN 61131-2)
Output
Lamp load 10 W
Actuator supply UA 24 V DC (EN 61131-2), max. 9 A
Switching current per output max. 1.6 A (short-circuit and overload protected)
Input
Sensor supply US 24 V DC (EN 61131-2), max. 200 mA (M12 female), short-circuit and overload protected
Type for 3-wire sensors or mechanical switches, PNP
Parameterization
PIN 4 Input/Output
PIN 2 Input/Diagnostic
Connections
Fieldbus CAN 1 Mbit/s; M12, A-coded
Sensor-system/actuator supply 7/8", 5-pole, 2× max. 9 A
I/O ports M12, 5-pole, A-coded
CANopen
Addressing Rotary switch 1...99
Diagnostic
Communication status via LED
Diagnostic via LED per module and channel
Diagnostic via BUS per module and channel
Actuator warning per channel via LED and BUS
Monitoring - under voltage yes
Monitoring - no voltage yes
Short-circuit and overload yes
Cable break per port
Commercial data
country of origin DE
customs tariff number 85176200
EAN 4048879051507
eClass 27242604
Pakke-enhed 1.000

Oplysninger vedrørende artikel:
  • Hent Datablad
  • Hent Approvals and certificates 55305_917-04.16_ce_z_b.pdf
  • Hent Approvals and certificates 55305_E201820-NRAQ_ul_z_b.pdf
  • Hent Approvals and certificates 55305_0000004f-cia200401-301v402-20-0027-Feb04_can_z_b.pdf
  • Hent Approvals and certificates 55305_E201820_NRAQ7_ulc_z_a.pdf
  • Hent China RoHS information EPUP-25_CHR_x_1.pdf
  • Hent Configuration Files MVK-MC_55305.zip
  • Hent Drawing Files 55305_p8_2_50.zip
  • Hent Drawing Files 55304_p8_2_50.zip
  • Hent Drawing Files 55294_dxf_x_a.zip
  • Hent Drawing Files 55294_stp_x_a.zip
  • Hent Installation Instructions 55304_ina_6_22.pdf
  • Hent Manuals 55388_hdb_x_12.zip
