M8 female 90° A-cod. solder pins 7000-08541-0000000
Product may differ from image

M8 female 90° A-cod. solder pins

4-pol., 0.25mm², 3,5 - 5mm

Art.No.: 7000-08541-0000000
Alternative product:    7000-08391-0000000
Weight: 0.008 kg
Country of origin:  DE
Available
Find similar Product
Ask question
 Recommend Product
Product Comparison
List price per piece:
Download to the Data Cart Download to Easy-Import-Export

Description

Female 90°
M8, 4-pole
with solder pins
Connection cross section: max. 0.25 mm²

Side 1
Family construction form M8
Degree of protection (EN IEC 60529) IP67
Electrical data | Supply
Operating voltage AC max. 30 V
Operating voltage DC max. 30 V
Current operating per contact max. 4 A
Installation
Connection cross section max. 0,25 mm²
Device protection | Electrical
Additional condition protection degree inserted, screwed
Mechanical data | Mounting data
Clamping range min. 3,5 mm
Clamping range max. 5 mm
Height 28 mm
Width 18,5 mm
Depth 12 mm
Environmental characteristics | Climatic
Operating temperature min. -25 °C
Operating temperature max. 85 °C

ECLASS-6.0 27279221
ECLASS-7.0 27440104
ECLASS-8.0 27440104
ECLASS-9.0 27440102
ECLASS-10.1 27440102
ECLASS-11.1 27440102
ECLASS-12.0 27440116
ETIM-5.0 EC001855
customs tariff number 85366990
GTIN 4048879224598
Packaging unit 1


Data Regarding Article:
  • Product-PDF
  • Construction files: STP 7000-08541_stp_x_a.zip (A)
  • Document: Installation guide 7000-08541-0000000_ina_x_02.pdf (02)
  • Information: Certificate of conformity Murrelektronik GmbH 17-12-23_(1) RoHS REACh exception 6c_DoC_z_a.pdf (04)
  • Information: Certificate of conformity Murrelektronik GmbH 23-12-23_(1) California Prop65 No Warning_DoC_z_a.pdf (01)
  • Information: Certificate of conformity Murrelektronik GmbH 13-12-23_(5) China RoHS 2 50EEP_DoC_z_a.pdf (01)
