D/A-CONVERTER 8-BIT - OUTPUT 4 ... 20MA

IN: 8 Bit - OUT: 4 ... 20mA

Art.No.:	44073
Alternative product:	44067
Weight:	0.16 kg
Country of origin:	CZ

Find similar Product

Ask question

Recommend Product

Product Comparison

Download to the Data Cart

Download to Easy-Import-Export

Description

D/A converter
8 Bit
4...20 mA
Input and output galvanically separated
For the converters with voltage output, the maximum output signal can be set to the operating voltage minus 2 V. Due to an internal current limitation the outputs are short-circuit proof and overload protected.

Technical Data

Electrical data

Accuracy (of full scale)	1 %

Electrical data | Supply

Operating voltage DC min.	21 V
Operating voltage DC max.	30 V
Operating current max.	150 mA
Open-circuit current	100 mA

Electrical data | Input

Input signal min.	0 V
Input signal max.	30 V
Input current max.	10 mA

Electrical data | Output

Output current max.	0,04 A

Mechanical data | Mounting data

Mounting method	geschnappt
Suitable for mounting type	mounting rail, (EN 60715)
Height	65 mm
Width	67,5 mm
Depth	86 mm

Environmental characteristics | Climatic

Operating temperature min.	0 °C
Operating temperature max.	50 °C

Connection data

Connection type 1

Connection	Screw terminals SK
Family construction form	terminal
Gender	female
No. of poles	6
PIN 1	+ US
PIN 2	+ US
PIN 3	0 V
PIN 4	0 V
PIN 5	I Out
PIN 6	I Out

Connection type 2

Connection	Screw terminals SK
Family construction form	terminal
Gender	female
No. of poles	9
PIN 1	D 8
PIN 2	D 7
PIN 3	D 6
PIN 4	D 5
PIN 5	D 4
PIN 6	D 3
PIN 7	D 2
PIN 8	D 1
PIN 9	0 V 1

Commercial data

ECLASS-6.0	27210990
ECLASS-6.1	27210990
ECLASS-7.0	27210990
ECLASS-8.0	27210990
ECLASS-9.0	27210990
ECLASS-10.1	27210990
ECLASS-11.1	27210990
ECLASS-12.0	27210990
ETIM-5.0	EC002477
customs tariff number	85437090
GTIN	4048879028615
Packaging unit	1

Downloads

Data Regarding Article:

Product-PDF
Document: Installation guide 44073_ina_6_10.pdf (10)
Information: Certificate of conformity Murrelektronik GmbH 09-11-20_(3) RoHS REACh exception 6c 7cI_DoC_z_a.pdf (04)
Information: Certificate of conformity Murrelektronik GmbH 06-02-23_(3) China RoHS 2 25EEP_DoC_z_a.pdf (01)
Information: Certificate of conformity Murrelektronik GmbH 20-10-21_(1) California Prop65 No Warning_DoC_z_b.pdf (01)
Information: Certificate of conformity UKCA 44073_1805-04.16_uk_z_a.pdf (A)
Information: EU declaration of conformity 44073_1805-04.16_ce_z_c.pdf (C)
Information: MTTF Report 44073_SN29500(40°C)-Berechnung_mttf_p_a.pdf (A)
