AMS 10-43/5 OPTO-COUPLER MODULE  50044
Product may differ from image

AMS 10-43/5 OPTO-COUPLER MODULE

N: 53 VDC - OUT: 53 VDC / 4 A
Art.No.: 50044
Alternative product:    52519
Weight: 0.1 kg
Country of origin:  CZ
Out of Stock - Contact Us for Availability
 Product Comparison
List price per piece:

Description

Transistor 4 A
24 V DC
Control voltage 230 V AC on request

General data
Mounting method DIN-rail mountable TH35 or G32 (EN 60715)
Temperature range -20...+60 °C
Test isolation voltage 3.75 kV
Housing Black plastic, flame retardant
Dimensions H×W×D 75×22.5×85 mm
Output
Switching time ON/OFF 4/7 µs
Saturation voltage (across output) max. 1.5 V DC
Switching voltage 4.5...53 V DC
Switching frequency max. 2 kHz/4 Hz (resist./ind.)
Switching current per output 10 mA...4 A
Input
Voltage range OFF 0...3 V DC
Voltage range ON 10...53 V DC
LED display LED (red)
Input current 14.5 mA
Product article number of manufacturer 50044

ECLASS-6.0 27371604
ECLASS-6.1 27371604
ECLASS-7.0 27371604
ECLASS-8.0 27371604
ECLASS-9.0 27371604
ECLASS-10.1 27371604
ECLASS-11.1 27371604
ECLASS-12.0 27371604
ETIM-5.0 EC001504
customs tariff number 85414900
EAN 4048879028028
Packaging unit 1


Data Regarding Article:
  • Download Data Sheet
  • Download Information: Certificate of conformity Murrelektronik GmbH 09-11.20_(3) RoHS&REACh exception 6c&7cI_DoC_z_a.pdf
  • Download Information: Certificate of conformity Murrelektronik GmbH 17-12.20_(3) China RoHS 2 25EEP_DoC_z_b.pdf
  • Download Information: Certificate of conformity Murrelektronik GmbH 20-10.21_(1) California Prop65 No Warning_DoC_z_b.pdf
  • Download Information: Certificate of conformity UKCA 50044_1510-04.16_uk_z_a.pdf
  • Download Information: EU declaration of conformity 50044_1510-04.16_ce_z_b.pdf
  • Download Information: MTTF Report 50044_SN29500(40°C)-BerechnungV1.4_mttf_p_a.pdf
