INDUCTIVCOUPLER 24V 5A 30KHZ 52700
Product may differ from image

INDUCTIVCOUPLER 24V 5A 30KHZ

Art.No.: 52700
Alternative product:    6652700
Weight: 0.026 kg
Country of origin:  CZ
Contact Us for Availability
Find similar Product
Ask question
 Recommend Product
 Product Comparison
List price per piece:
Download to Easy-Import-Export

Description

Inductive switching signal transmission
Wear-free switching
No operating voltage at output
Switching frequency: max. 30 kHz
Switching current up to 5 A
Screw terminals
Certificate
Certificate
Certificate

Electrical data | Input
Input voltage OFF DC min. 0 V
Input voltage OFF DC max. 5 V
Input voltage DC 24 V
Input voltage DC min. 15 V
Input voltage DC max. 30 V
Input current DC max. 32 mA
Electrical data | Output
Quiescent current OFF max. 0,025 mA
Switching frequency inductive max. 3000 Hz
Switching frequency ohmic max. 30000 Hz
Current switching min. 1 mA
Switching current max. 5 A
Diagnostics
Status indication LED yellow
Device protection | Electrical
Rated surge voltage 1,5 kV
Degree of protection (EN IEC 60529) IP20
Device protection | Media
Flame resistance flame retardant
Mechanical data | Material data
Color housing black
Material housing Plastic
Mechanical data | Mounting data
Mounting method geschnappt
Suitable for mounting type (EN 60715), mounting rail
Height 78 mm
Width 6,2 mm
Depth 71 mm
Environmental characteristics | Climatic
Operating temperature min. -20 °C
Operating temperature max. 60 °C
Storage temperature min. -40 °C
Storage temperature max. 80 °C

ECLASS-6.0 27371604
ECLASS-6.1 27379090
ECLASS-7.0 27379090
ECLASS-8.0 27379090
ECLASS-9.0 27379090
ECLASS-10.1 27379090
ECLASS-11.1 27379090
ECLASS-12.0 27379090
ETIM-5.0 EC001504
customs tariff number 85365080
GTIN 4048879329538
Packaging unit 1


Data Regarding Article:
  • Download Product-PDF
  • Download Approval: UL Registered CA 52700_E140415-NKCR8_urc_z_b.pdf
  • Download Approval: UL Registered US 52700_E140415-NKCR2_ur_z_b.pdf
  • Download Construction files: P8 52700_p8_2_10.zip
  • Download Document: Installation guide 52700_ina_x_11.zip
  • Download Information: Certificate of conformity Murrelektronik GmbH 06-02-23_(3) China RoHS 2 25EEP_DoC_z_a.pdf
  • Download Information: Certificate of conformity Murrelektronik GmbH 20-10-21_(1) California Prop65 No Warning_DoC_z_b.pdf
  • Download Information: Certificate of conformity Murrelektronik GmbH 09-11-20_(3) RoHS REACh exception 6c 7cI_DoC_z_a.pdf
  • Download Information: Certificate of conformity UKCA 52700_1547-04.16_uk_z_a.pdf
  • Download Information: EU declaration of conformity 52700_1547-04.16_ce_z_b.pdf
  • Download Information: MTTF Report 52700_SN29500(40°C)-BerechnungV1.4_mttf_p_a.pdf
