MASI67 I/O MODULE
Product may differ from image

MASI67 I/O MODULE

4 digital inputs
Art.No.: 56413
Weight: 0.18 kg
In production
 Product Comparison
List price per piece:

You might also like

Digital inputs
DI4 - 0.2 A (AB) - 4× M12
Y-wiring
Connection cables are in the online shop under "Connection Technology".
Housing fully potted.
Technical Data
Bus voltage (AS-Interface) 26.5...31.6 V DC
Profile (IO/ID/ID2 code) S-0.A.2
Addressing via built-in address port or master
Y-wiring yes
Address range 1...62 (1...31 A or B)
Total current max. 250 mA
General data
Mounting method DIN-rail mountable (EN 60715) or screw fixing
Temperature range -20...+60 °C (storage temperature -20...+70 °C)
Protection IP67
Dimensions H×W×D 94×60×39 mm
Input
Sensor supply US max. 170 mA from AS-Interface (short-circuit and overload protected)
Type for 3-wire sensors or mechanical switches, PNP
Diagnostic
Communication status via LED
Diagnostic via LED per module
Diagnostic via BUS yes
Commercial data
country of origin DE
customs tariff number 85176200
EAN 4048879049009
eClass 27242604
Packaging unit 1.000
Data cableShow all
Sensor-actuator cableShow all

Data Regarding Article:
  • Download Data Sheet
  • Download Approvals and certificates 56413_5032-04.16_ce_z_c.pdf
  • Download Approvals and certificates 56413_52702_asi_z_a.pdf
  • Download China RoHS information EPUP-20_CHR_x_1.pdf
  • Download Drawing Files 56413_p8_2_50.zip
  • Download Drawing Files 55033_p8_2_50.zip
  • Download Installation Instructions 56400_ina_6_38.pdf
  • Download Manuals 56411_hdb_x_15.zip
